A structural steel moment connection joins a framing beam to a frame column using continuous plates top and bottom and a bolted shear tab at the beam web. The beam flanges connect to the continuous plates with complete-joint-penetration welds reinforced with backing bars and field-welded 5/16-inch fillets. The beam web connects to the column flange through a bolted plate with a 5/16-inch fillet weld at the erection plate. Continuous plates extend on both sides of the column and are detailed per specific structural notes.
C.J.P. T&B SEE NOTE 4 FRAME COLUMN 2" 2" 3" SEE NOTE 1 5/16 AT ERECTION PL C.J.P. BEAM WEB TO COLUMN FLANGE CONT. PL T&B, BOTH SIDES - SEE 1 S-155523 C.J.P. SEE NOTES 2 & 4 5/16 BACKING TO CONT. PLATE 5/16
