S-5FP7E — Lube Containment Pit Removable Access Cover

Structural · S-5FP7E

Lube Containment Pit Removable Access Cover

Units: metric
Sheet: S-MB-5.05
Discipline: Structural

Materials

Metal (misc.)Steel

Elements

Floors / Slabs Roof / Floor Openings

Text on the drawing

250 DIA 200 DIA TYP 3 CLR BAND GRATING REMOVABLE ACCESS COVER FROM GALVANIZED PL 5 GRATING LUBE CONTAINMENT PIT REMOVABLE ACCESS COVER

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
