A wide flange steel column welds to a base plate with a five-sixteenths inch fillet weld. The assembly bears on one and one-half inches of nominal non-shrink grout over a concrete foundation. Threaded anchor rods with T-anchors secure the base plate, complete with leveling nuts, washers, and top nuts. An optional grout hole is centered in the base plate, and bolt projections and dimensions are detailed per schedule.
A A WASHER AND NUT SECTION A-A "L" THREADED 6" MIN. BOLT PROJECTION CL OF COLUMN AND PLATE WF COLUMN REF. PLAN 5/16 GROUT HOLE OPTIONAL "T" ANCHOR ROD REF. SCHEDULE 2/S6.01 "B" 5/16 "N" BASE PLATE REF. SCHEDULE 2/S6.01 CL OF COLUMN AND PLATE 1 1/2" NOMINAL NON-SHRINK GROUT LEVELING NUT TYP. X" TYP. X"
