An HSS6x2x1/4 hollow structural section rail is laid flat and positioned at a top of steel elevation of 143'-4" and 141'-2". It connects adjacent structural framing members including a W12X16 beam at elevation 143'-0" and a W21X50 beam at elevation 143'-0". A C7 channel is integrated into the steel assembly.
W21X50 <143'-0"> W12X16 143'-0" C7 HSS6x2x1/4 RAILS, LAID FLAT, TOS = 143'-4" & 141'-2" _______________ S-212 7
