A reinforced concrete curb rises up to four feet maximum from the top of the structural slab edge. The curb features a three-quarter inch typical chamfer at its top outside corner and is reinforced with number five vertical and horizontal bars placed at twelve inches on center, centered in each face and each way. Additional number four continuous bars are anchored into the slab edge to tie the curb assembly into the structural floor.
PER PLAN MAX 4'-0" T/CURB PER PLAN T/SLAB PER PLAN 3/4" CHAMFER TYP ADDL #4 CONT TALL CURB AT SLAB EDGE #5 @ 12"OC EF EW CTRD CONC CURB PER PLAN
