Typical toilet room signage placement details the standard mounting height and horizontal offset for door identification signs. The drawing specifies a one-foot dimension from the door centerline to the sign edge for both women and men restroom entries. Signage is mounted adjacent to the door frame at a consistent height for accessibility compliance.
