Structural detail of an eccentric stair midlanding support connection framing into a steel beam with a web stiffener. A broken-back hollow structural section or channel stair stringer connects to a hanging beam and hanger member provided by the stair supplier. The connection occurs at the centerline of the structural steel beam. Top and bottom connections from the hanger member to the stair midlanding and floor beam are coordinated by the stair supplier. The stair deck is omitted for clarity, and a proposed adequate alternative by the stair supplier is also acceptable.
A A STL BM WEB STIFF, SEE GSN BROKEN BACK HSS OR CHANNEL STAIR STRINGER BY STAIR SUPPLIER BM HSS OR CHANNEL HANGING BEAM BY STAIR SUPPLIER, TYP HANGER MEMBER AND CONN TOP & BOT (TO STAIR MIDLANDING AND FLOOR BEAM) BY STAIR SUPPLIER CONNECTION TO OCCUR AT CENTERLINE OF BEAM SECTION A-A STAIR DECK NOT SHOWN FOR CLARITY A PROPOSED ADEQUATE ALTERNATIVE BY STAIR SUPPLIER IS ALSO ACCEPTABLE A A STL BM WEB STIFF, SEE GSN BROKEN BACK HSS OR CHANNEL STAIR STRINGER BY STAIR SUPPLIER BM HSS OR CHANNEL HANGING BEAM BY STAIR SUPPLIER, TYP HANGER MEMBER AND CONN TOP & BOT (TO STAIR MIDLANDING AND FLOOR BEAM) BY STAIR SUPPLIER CONNECTION TO OCCUR AT CENTERLINE OF BEAM SECTION A-A STAIR DECK NOT SHOWN FOR CLARITY A PROPOSED ADEQUATE ALTERNATIVE BY STAIR SUPPLIER IS ALSO ACCEPTABLE
