Section B-B shows an MC 12"x10.6 channel paired with an MC 8"x8.5 channel above, connected to a concrete wall panel via a 3"x3"x1/4" by zero-feet eight-inch clip angle secured with two 5/8" diameter by 4" minimum embedment Hilti Kwik Bolt TZ anchors or equal. Section A-A shows the same channel members connected using a 5"x3"x1/4" by zero-feet eight-inch shop-installed clip angle with a three-sixteenths-inch fillet weld, and two 5/8" diameter full-threaded weld stud anchors shop-installed on the MC 12"x10.6 channel.
