A pipe sleeve penetrates a metal roof deck and is capped with an 18 gauge plate fastened by number ten sheet metal screws spaced at 6 inches on center each way. Sizing criteria specify a 12 inch square plate for pipe diameters under 4 inches, a 24 inch square plate for diameters up to 8 inches, and a 36 inch square plate for diameters under 12 inches.
PIPE SLEEVE 18 GA PLATE WITH #10 SHEET METAL SCREWS AT 6" O.C. EACH WAY METAL ROOF DECK PLAN VIEW 36" SQ. < 12"DIA 24" SQ. ≤ 8"DIA 12" SQ. ≤ 4"DIA
