A crank stringer and modified stair pan support a concrete-filled metal deck resting over a structural steel supporting beam. An inverted angle measuring 2 1/2 by 2 1/2 by 3/16 inches acts as a deck support, with the stringer coped to suit the connection geometry. The stair decking returns by 2 1/2 inches onto the support assembly sized per plan.
RETURN SUPPORT DECKING ON MODIFIED STAIR PAN CRANK STRINGER AND COPE TO SUIT 2 1/2" 1'-8" SEE PLAN INV. L 2 1/2 x 2 1/2 x 3/16 DECK SUPPORT 1903 STAIR DETAIL
