Reinforcing bars feature standard 90-degree and 180-degree hooks measured from the face of support. The embedment length ldh is dimensioned along with bar diameter D for each hook configuration. Tension values are indicated as T equals As times fy. Additional sizing references direct the user to standard hook and tie details.
REINFORCING BAR T=Asfy FACE OF SUPPORT FACE OF SUPPORT STANDARD HOOK 90° HOOK 180° HOOK T=Asfy D D "ldh" FOR STANDARD HOOK SIZES, SEE "STANDARD HOOK AND TIE DETAILS" "ldh" "ldh" STANDARD HOOK
