Reinforcement for a circular beam web penetration with diameter D where the opening size falls between one-quarter and one-half of the total beam depth d. A web plate sized per schedule is centered over the penetration, maintaining a minimum distance of d over four from the top and bottom flanges. Spacing between multiple penetrations requires a minimum clear distance of D plus one inch, with edge distances of D over two or four inches minimum. When penetration diameter D is less than one-quarter of beam depth d, no web plate is required. Continuous web plates must be used when two or more penetrations occur together.
(USE "D" OF LARGEST PENETRATION) WHERE 1/4 d < D < 1/2 d ELEVATION NOTE: NO WEB PL REQUIRED WHEN "D" < 1/4 "d" PENETRATION WHERE OCCURS, USE CONTINUOUS PL FOR TWO OR MORE PENETRATIONS TOGETHER CIRCULAR BEAM PENETRATION (DIAMETER = "D") WEB PL (SEE SCHED) BEAM DEPTH "d" MIN d/4 MIN d/4 "D" WEB PL (SEE SCHED) "d" WEB PL/2 "D" MIN TYP (4" MIN) D/2 D+1" (4" MIN) D/2
