A structural steel pipe column bears on a reinforced concrete column with a two-inch layer of non-shrink grout beneath the base plate. The base plate is secured by anchor bolts featuring square plates with nuts at top and bottom. A vertical kerf plate made from Grade 50 steel is welded inside the pipe column with quarter-inch fillet welds. Additional steel pipes intersect the column at an angle, connected with three-sixteenth-inch typical cap plates and quarter-inch fillet welds. A quarter-inch cap plate seals the top of the main pipe column.
10" 1 1/2" TYP 10" 7° 7° 2" 3" 1/4 1/4 1/4 1/4 1/4 1/4 20" 1/4 20" CONC COLUMN PIPE PER PLAN PIPE COL 3/16" CAP PL TYP PL 1" x 3" SQ W/ NUT TOP & BOT 2" NON-SHRINK GROUT KERF PL 3/4" x REQD (GR50) PL 3/4"x4" x REQD WORK POINT CAP PL 1/4" 3/4" = 1'-0"
