A steel wide flange beam connects to an HSS beam using a WT section web connection sized per the schedule. The WT section web size matches the typical bolted web plate connection schedule, with a flange width of four inches minimum and a flange thickness not less than the web thickness. The wide flange beam is coped as required, maintaining a maximum three-inch clearance from the HSS centerline. Cope dimension A is equal to one-half the web thickness plus one-sixteenth of an inch.
MAX 3" HSS BLW STL WF BM WT SECTION WEB SIZE TO MATCH TYP BOLTED WEB PL CONNECTION SCHED FLANGE WIDTH 4" MIN. FLANGE THICKNESS NOT LESS THAN WEB THICKNESS / (6 XS801) A COPE AS REQD A = 1/2 WEB THICKNESS + 1/16" HSS BM, SEE PLAN 6 XS801
