Structural · S-4Z33S

Steel Beam in Stud Wall at Roof Parapet

Materials

Steel Timber / Wood Brick

Elements

Beams Walls Facades / Cladding Roofs Parapets Floors / Slabs Decks Arches Bracing Insulation Connections / Plates

Connections

Bracing Connection Welded Connection Deck Attachment

About this detail

A steel beam supports a roof deck with a downturned angle and a bent plate edge condition, intersecting a steel stud wall with a deflection track and brick veneer. The structural steel beam features stiffener plates sized per the structural plan. A roof deck bears on the steel framing with deck welds specified at three inches minimum. An L4x4x1/4 downturned angle is welded to the roof deck edge with a quarter-inch fillet weld at twelve inches on center. A quarter-inch by four-inch bent plate matches the slope of the high roof deck as detailed by the architect. The exterior wall assembly consists of steel stud framing with a deflection track, exterior insulation, and a brick veneer facade.
