Structural · S-4YSHE

Slab Edge Reinforcing Angle at Glulam Beam

Materials

Elements

About this detail

A glulam beam supports a multi-layer timber floor deck with a three-inch maximum overhang to the deck edge. An L6x6x7/16 structural steel slab edge reinforcing angle is anchored at levels 4, 7, 9, 11, and 13. A gauge metal edge form is secured to the L6x6 angle using powder-actuated fasteners. Vertical fasteners secure the assembly through the deck layers into the beam below.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
