Concrete grade beam reinforcement extends from a column footing. The assembly incorporates longitudinal reinforcing bars with Class B splices at each end, enclosed by number 4 ties spaced per the structural schedule. A three-inch concrete clear cover is maintained throughout the member. Overall dimensions and spacing requirements are referenced to the structural drawings and schedules.
TYP AT INT BM SPLICE SEE SCHED ON SHT S400 TYP AT EXT BM FOOTING SEE PLAN FACE OF FOOTING GRADE BEAM REINF SEE SCHEDULE VARIES - SEE PLAN SEE SCHEDULE FOR SPACINGS #4 TIES GRID LINE, OF COL SEE PLAN "CLASS B" TYPICAL 3" CLR - SEE SCHEDULE GRADE BEAM DEPTH 10 S-403 14 S-403 EA END "CLASS B" SPLICE TYP 13 TYP GRADE BEAM REINFORCEMENT
