This connection assembly joins a structural steel column oriented perpendicular to a beam web using a bearing plate measuring 3/4 inch by column flange width plus 1 inch by column depth plus 1 inch. The connection is secured with four 3/4-inch diameter bolts arranged at the beam gauge. A column cap plate matches the bearing plate size, and partial-height stiffener plates measuring 3/8 inch thick are aligned with the column web and welded on two sides with typical 1/4-inch fillet welds.
COL PER PLAN COLUMN BELOW CL COL BEAM PER PLAN T/STL PER PLAN BRG PL3/4 x COL FLANGE WIDTH + 1" x COL DEPTH + 1" W/ (4) 3/4"Ø BOLTS AT BEAM GA COL CAP PLATE TO MATCH BRG PLATE PARTIAL HEIGHT STIFF PL3/8 x AS SHOWN, ALIGNED W/ COL WEB, TYP 1/4 1/4 (2) SIDES, TYP 1/4 TYP B SECTION COL PER PLAN COLUMN ABOVE BEAM PER PLAN T/STL PER PLAN BRG PL3/4 x COL FLANGE WIDTH + 1" x COL DEPTH + 1" W/ (4) 3/4"Ø BOLTS AT BEAM GA COL BASE PLATE TO MATCH BRG PLATE B SECTION BEAM END WHERE OCCURS C L C L MAX 2" TYP 1 1/2" C L SEE NOTE 1 1/2" TYP BEAM PER PLAN COL PER PLAN 1/4 1/4 CL COL/BEAM SECTION B
