A structural steel beam supports a metal roof deck and steel joist adjacent to an exterior cold-formed metal stud wall. The wall consists of 6-inch 18-gauge metal studs spaced at 16 inches on center with exterior sheathing sized per architectural drawings. A continuous top track caps the 6-inch 18-gauge cold-formed steel framing at the glazing head, where a top-of-window elevation marker is indicated. A hollow structural section brace connects to the support assembly per detail 8/S521. Additional framing and connection details are referenced via detail bubbles 10/S521, 12A/S511, and 12C/S511.
SEE ARCH BRACE PER 8/S521 AT HSS SUPPORT METAL ROOF DECK STEEL JOIST, SEE PLAN STEEL BEAM, SEE PLAN 6"x18GA (600T125-43) x CONT TOP TRACK GLAZING, SEE ARCH T.O. WINDOW EXTERIOR SHEATHING, SEE ARCH 6"x18GA (600S162-43) METAL STUDS AT 16" O.C. TYPICAL AT GLAZING 6"x18GA (600S162-43) METAL STUDS AT 16" O.C. TYPICAL 12C S511 10 S521 12A S511
