A structural steel beam frames into a reinforced concrete collector beam using A572-50 top and bottom plates welded with C.P. U.T. welds. Collector reinforcement is tied into the concrete assembly using Lenton C2 weldable couplers and Lenton form savers per elevations and plans. Tie layouts are provided above and below the shown collector bars. The assembly is detailed with specific dimensional clearances and reinforcing spacing.
10" 3" 4" 5" 2½" 2½" 5" 4½" 4½" 4" 2" 2" 4" COLLECTOR REINF. PER PLAN 2¾" A572-50 T&B COLLECTOR REINF. PER EL.'S W/ LENTON FORM SAVERS TIE LAYOUT ABOVE & BELOW COLLECTOR BARS SHOWN COLLECTOR REINF. PER EL.'S W/ LENTON C2 WELDABLE COUPLERS REINF. PER EL.'S & A B C.P. U.T. T&B STL BM PER PLAN W.P.
