Foundation footings bear on engineered structural fill extending down to native soils per plan and the soils report. The footing width equals its depth, with a minimum six-inch clearance below finish grade. Backfill slopes away from the structure, and a vapor barrier is placed over a free-draining granular base beneath the slab.
FINISH GRADE, SLOPE AWAY FROM STRUCTURE BACKFILL VAPOR BARRIER AS REQUIRED BY SOILS REPORT FREE DRAINING GRANULAR BASE WIDTH = DEPTH FOOTINGS SHALL BEAR ON ENGINEERED STRUCTURAL FILL EXTENDING DOWN TO NATIVE SOILS PER PLAN AND SOILS REPORT. SEE PLAN SEE EARTHWORK NOTES AND SOILS REPORT FOR ADDITIONAL INFORMATION. 6" MIN.
