S-4PS7A — Section F-F

Structural · S-4PS7A

Section F-F

Units: imperial
Sheet: S022-2
Discipline: Structural

Materials

Elements

Anchors / Embeds Connections / Plates

Connections

Base Plate / Anchorage Embed Plate

Text on the drawing

SECTION F-F (7)-3/4"Ø EXP ANCHORS, 6" EMBEDMENT L4x4x3/8 L4x4x3/8 2" 8" 8" 2" 5/16 10" SECTION F-F (7)-3/4"Ø EXP ANCHORS, 6" EMBEDMENT L4x4x3/8 L4x4x3/8 2" 8" 8" 2" 5/16 10"
