Hollow structural section columns are slotted to receive shear plates, allowing larger beams to bear on continuous shear plates welded per schedule. Welds connect the shear plates to the structural steel columns and beams as indicated in the typical details. Multiple framing configurations are shown including three-sided and four-sided connection conditions.
SLOT COLUMN AT SHEAR PL's - LARGER BEAMS TO BEAR ON CONTINUOUS SHEAR PL SLOT COLUMN AT SHEAR PL's - LARGER BEAMS TO BEAR ON CONTINUOUS SHEAR PL PLAN VIEW (3-SIDED CONDITIONS SHOWN) PLAN VIEW (4-SIDED CONDITION SHOWN) WELD PER SCHEDULE 1/S0.21 TYP. WELD PER SCHEDULE 1/S0.21 TYP. SLOT COLUMN AT SHEAR PL's - LARGER BEAMS TO BEAR ON CONTINUOUS SHEAR PL WELD PER SCHEDULE 1/S0.21 TYP.
