A custom mullion profile integrates a one-inch-wide space for a between-glass venetian blind, featuring removable stops on both sides and an internal blind tilt control as required. The overall assembly height accommodates a throat opening plus one inch, with equal spacing dimensions of five-eighths of an inch and two inches configured around the structural profile.
5/8" 2" 5/8" 2" THROAT OPENING + 1" MULLION - BETWEEN GLASS VENETIAN BLIND W9 REMOVABLE STOP (BOTH SIDES) BLIND TILT CONTROL AS REQD AS REQD EQ EQ
