A steel beam sized per plan frames into a concrete masonry unit wall using a standard single plate beam connection, designated as SEP-3. The concrete masonry unit wall features typical bond beams and a sloped concrete bond beam at the upper level supporting flashing detailed on architectural drawings A-351 through A-353. A roof deck sized per plan bears above the beam with a designated ED-1 component.
CMU WALL PER PLAN BOND BM TYP RF DK PER PLAN SLOPED CONC BOND BM FLASHING PER ARCH DWG A-351 - A-353 ED-1 BM PER PLAN STD SINGLE PL BM CONN SEP-3
