The steel column is anchored to a concrete footing with a base plate assembly, utilizing a one and one-half inch shim and grout space. The slab-on-grade is thickened around the column base to provide adequate cover, with a bond breaker installed between the slab and the footing. A three-eighths inch continuous expansion joint material separates the slab from the column assembly. Reinforcement and anchor rod specifications are referenced to the footing schedule and associated structural details.
Text on the drawing
GRID T/ FOOTING RE: PLAN SLAB-ON-GRADE ~ RE: PLAN T/ SLAB RE: PLAN 3/8" EXP JT MATERIAL x CONT, RE: RE: FOOTING SCHEDULE CLR 0'-3" RE: FTG SCHED STEEL COLUMN, RE: PLAN AND COLUMN SCHEDULE THICKEN SLAB TO COVER COLUMN BASE PLATE. PROVIDE BOND BREAKER BTWN SLAB AND FOOTING RE: FOR ANCHOR ROD AND BASE PLATE INFO RE: FOOTING SCHEDULE FOR REINF AND GROUT 0'-1 1/2" SHIM 5/S-60004 3/S-60000 UNDERGROUND DRAIN RE: CIVIL
