Cored openings in composite steel decks require metal deck reinforcement when maximum diameters are exceeded, and groups of cores spaced below minimum spacing must be treated as a single opening. Deck heights of one and a half inches permit unreinforced core diameters up to three inches with an eighteen inch minimum spacing, while two and three inch deck heights allow up to six inch diameters with a thirty-six inch minimum spacing. Where core spacing is less than the minimum, reinforcement is provided per the designated details or groups of cores are treated as a single opening. Supports for closure plates are welded to the underside of the steel deck.
5300-18 5300-04 20 - 24 - 24 - 18 19 IN COMPOSITE STEEL DECK TYP. CORED OPENINGS AT COLUMN TYP. SUPPORT FOR CLOSURE PLATE STRING OF CORES ISOLATED CORES DMAX. W/O REINF. W/O REINF. S MIN. DECK HEIGHT OR GROUP OF CORES AS A SINGLE OPENING PER MIN. 2. WHERE CORE SPACING IS LESS THAN S , REINFORCE 3" 6" 6" 18" 36" 36" 1 1/2" 2" 3" NOTES: 1. WHERE D IS EXCEEDED, REINFORCE METAL DECK FOR OPENING PER . WELD SUPPORT TO UNDERSIDE OF STEEL DECK. MAX. S D D
