Precast trench drains are embedded within a concrete slab featuring six inches minimum thickness and parallel control or construction joints. The assembly incorporates continuous epoxy-coated number four reinforcing bars spaced at twelve inches on center alongside five continuous number four reinforcing bars. A pourback strip is provided adjacent to the trench drain to facilitate alignment and placement. Coordination with mechanical and architectural drawings is required for sizing and positioning.
1'-0" 1'-0" 6" MIN. 6" MIN. POURBACK STRIP PRE-CAST TRENCH DRAIN VERIFY W/ MECH AND ARCH DWGS CONTROL/ CONST JOINT CONTROL/ CONST JOINT TRENCH DRAIN, SEE ARCH (5) #4 x CONT POUR JOINT #4 AT 12"oc (EPOXY COATED) #4 AT 12"oc (EPOXY COATED) (5) #4 x CONT (EPOXY COATED) 1'-0"
