Cold-formed steel framing connections feature header members intersecting double jambs with two distinct configuration alternatives. The top detail shows stud flanges cut to allow the webs to run continuously over the jamb with double jambs installed where required. The bottom detail incorporates a square plate fastened to the header and jamb using ten number ten screws on each side. Additional framing attachment uses two number ten screws spaced at sixteen inches on center typically.
A A ALTERNATE (NO PLATE) CUT STUD FLANGE AND RUN WEBS OVER JAMB DOUBLE JAMB WHERE OCCURS 3/4 24 3/4 24 AT DBL JAMBS ELEV VIEW PL54 MILx6" SQ W/(10) #10 SCREWS EA SIDE OF HEADER JAMB PER ELEV 3/4 24 3/4 24 AT DBL JAMBS (2) #10 SCREWS @ 16" TYP
