A channel stringer connects to a supporting steel member using a quarter-inch thick plate welded with three-sixteenths inch fillets. Three three-quarters inch diameter machine bolts secure the connection through the plate and channel web. Edge distances are three inches horizontally and one and one-half inches vertically with a three-inch bolt spacing. The channel profile and overall finish are sized per plan.
STEEL STAIR FRAMING CONN. 5 A 3" 1 1/2" 1 1/2" 3" C12 x SEE PLAN 3/16 3/16 W/ 3-3/4" DIA. M.B. 1/4" THK. PLATE TYP. STRINGER SEE PLAN SEE PLAN FOR FINISH
