Anchor bolts are embedded into concrete masonry unit walls with a minimum one-inch grout clearance all around the bolt. Minimum bolt spacing is twelve bolt diameters with a minimum edge distance of six bolt diameters. The embedment schedule specifies required embedment depths for bolt sizes ranging from one-half inch to one inch in diameter, with a minimum edge distance of 1.5d.
NOTE: MINIMUM BOLT SPACING SHALL BE 12 BOLT DIAMETERS WITH A MINIMUM EDGE DISTANCE OF 6 BOLT DIAMETERS. FACE OF CMU WALL ANCHOR BOLT SEE SCEHDULE BOLT EMBEDMENT SCHEDULE BOLT SIZE EMBEDMENT 1/2"Ø 5/8"Ø 3/4"Ø 7/8"Ø 1"Ø 4" 4" 5" 6" 7" 1.5d CONC BLOCK 1" MIN GROUT ALL AROUND BOLTS SEE SCHED MIN EMBED MIN 1.5d
