A stepped slab on grade construction joint features a thickened edge transition. Two continuous number 4 reinforcing bars run longitudinally through the joint assembly. The concrete slab rests on prepared subgrade with specified thickness dimensions and dimensional clearances as indicated per plan.
CONSTRUCTION JOINT 2-#4 CONT 1' - 4" 8" 1' - 4" 3" SLAB ON GRADE PER PLAN TYP 3" MIN 8" SEE PLAN OVER 4" 12" MAX
