A built-up light-gauge steel jamb connects at the slab and deck edge using an L8x4x7/16 angle centered on the jamb, secured with two rows of four 1/4-inch diameter by 3-1/2-inch Simpson SDS screws. Continuous L6 angles with fasteners tie into the deck edge adjacent to the jamb. A glulam column cap steel plate aligns with the columns and connects with five number 14 self-tapping sheet metal screws at each contact point. Clips on each face of the jamb provide additional fixity and connection as required by plan.
SP & EF PER PLAN BUILT-UP LIGHT GA JAMB AS OCCURS CLIP EA FACE JAMB, FIXITY & CONNECTION AS REQD PER & L6 CONT & FASTENERS PER 8 S5.4.1 PLAN TYP FASTENERS EA SIDE OF JAMB FASTENERS 1 1/2" 4 1/2" 1" 1/4" 1/4" 1" 1 1/2" 3" 3" 3" 1 1/2" L8x4x7/16 x 1'-0" (LLH) CTRD ON JAMB 2" 1 1/2" (2) ROWS OF (4) 1/4"Ø x 3 1/2" SIMPSON SDS 3 S5.6.1 7 S5.6.1 4 S5.6.1 SIM EDGE OF SLAB / EDGE OF DECK 16GA TRACK 6"x14GA NS & FS PLAN VIEW A-A 1'-4" MAX A A SECTION AT COL JAMB STL ALIGNED w/ COLUMNS (5) #14 SMS EA CONTACT GL COL CAP STL GL COL CAP STL 1/8 TYP DETAIL S6.1.4 3" = 1'-0" 5 BUILT-UP JAMB CONNECTION AT DECK EDGE LGD5
