This plan section details a pipe post or column connection with wide-flange beams framing into the assembly. The circular column or pipe above is fitted with stiffener plates at the top and base plates sized per project specifications. A five-sixteenths inch fillet weld is specified at each end of the plates. A wide-flange beam frames into the column with a one-half inch minimum clearance, accompanied by an optional trim plate at the contractor's discretion. Additional information and plate details are referenced on sheet seventeen.
1. SEE 17/- FOR INFO NOT SHOWN NOTES: 5/16 EA END OF PL, TYP PLATE BELOW PER 17/- STIFF PL PER PER 17/-, TYP BM PER PLAN WF BM PER PLAN TYP 1/2" MIN TYP 1/2" MIN TYP 1/2" MIN TRIM PL AT CONTRACTORS OPTION PLATE PER 17/-, TYP PLAN SECTION MIN 1/2" 1'-6 1/2" MAX PIPE ABV
