Concrete floor slab openings are reinforced with number four bars placed around the perimeter and diagonally at the corners. Diagonal bars extend two feet typically from each corner of the opening with a one-and-a-half-inch typical clearance. Only diagonal bars are required for openings smaller than one foot by one foot. Unshown openings larger than one foot square and closely spaced multiple holes require submission to the structural engineer for review.
STRUCTURAL FILL PER PLAN TYP. 2'-0" TYP. 2'-0" #4 BARS TYP. 1 1/2" ONLY DIAGONAL BARS ARE REQ'D FOR OPENINGS SMALLER THAN 1'-0" x 1'-0" NOTES: ALL OPENINGS NOT SHOWN ON THE STRUCTURAL DRAWINGS THAT ARE LARGER THAN 1'-0". SQUARE AND ALL MULTIPLE HOLES SPACED CLOSER THAN 3x LARGEST OPENING DIMENSION. SHALL BE SUBMITTED FOR REVIEW TO THE STRUCTURAL ENGINEER. S501 | 3/4" = 1'-0" 10 SLAB EDGE W/ TRENCH DRAIN
