A gusset plate designated T1 connects a structural steel beam and brace to a steel column. An L4x3-1/2x3/8 angle with long leg vertical connects the top and bottom of the gusset plate with a minimum of two bolts on each leg. The brace connects to the gusset plate using N1 bolts as specified in drawing notes. The supporting beam requires a minimum depth of twelve inches.
DETAIL S76 COL BEAM BEAM GUSSET PL "T1" L4x 3 1/2x 3/8" (LLV) T & B OF GUSSELT PL, MIN 2-BOLTS EA LEG IF ANGLE CONN (TYP) "N1" BOLTS SEE NOTE 3 THIS DWG 12" MINIMUM BEAM DEPTH
