A steel column connection features external continuity plates that may be extended for slab edge or deck support at the fabricators discretion. A steel beam connects to the column with no protected zone on the beam. A bent plate or perimeter angle by others is provided, with welded attachments to continuity plates and/or top plates restricted to a maximum of three-sixteenths of an inch and positioned so as not to impair bolt installation. The maximum dimension between components is limited to eighteen inches.
STEEL COLUMN, SEE PLAN & SCHEDULE EXTERNAL CONTINUITY PLATE MAY BE EXTENDED FOR SLAB EDGE OR DECK SUPPORT AT FABRICATORS DISCRETION STEEL BEAM SEE PLAN NO PROTECTED ZONE ON BEAM BENT PLATE OR PERIMETER ANGLE BY OTHERS. WELDED ATTACHMENT TO CONTINUITY PLATES AND/OR TOP PLATES NOT TO EXCEED 3/16" AND NOT TO IMPAIR BOLT INSTALLATION BENT PLATE OR PERIMETER ANGLE BY OTHERS 18" MAX
