Structural · S-47Z6R

Vehicle Barrier Column Detail

Materials

Concrete Steel

Elements

Columns Beams Floors / Slabs Arches Anchors / Embeds Reinforcing

Connections

Rebar Splice / Development

About this detail

A concrete vehicle barrier column is supported by a thickened post-tensioned concrete slab edge and beam assembly. A construction joint separates the column base from the slab, anchored by four number four U-dowels spaced equally within the column cage. Two post-tensioned tendons run longitudinally along the slab edge alongside specified chord steel. The adjacent post-tensioned concrete beam features top and bottom reinforcement with hooked ends.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
