A wide-flange steel column connects to a cap plate sized to match the flange thickness plus a maximum one-quarter inch. A five-sixteenth inch fillet weld secures the assembly, with backing bars and weld tabs to be removed after the root pass is cleaned and inspected. Slip-critical A490 bolts in Class B connections fasten the vertical plates to the column flanges. A three-eighths inch typical weld is detailed at the base of the connection plates.
COL W-COLUMN, SEE PLAN OR SCHEDULE tf 3/8 TYP. CAP PLATE = tf (MAX. +1/4) BACKING BAR TO REMAIN, REMOVE WELD TABS TYP. REMOVE BACKING BAR & WELD TABS 5/16 AFTER ROOT IS CLEAN AND INSPECTED (TYP.) 1/2" OVERHANG A490 BOLTS SLIP CRITICAL CONECTION (CLASS B) L= S Lev
