A wide-flange beam frames into the web of a wide-flange column, with sizes and configurations specified per plan. The beam connects to both sides of the column web where indicated. A detail reference bubble points to sheet S-211.
WF COL, SEE PLAN WF BEAM (BOTH SIDES WHERE OCCURS), SEE PLAN 4A S-211 _______________
