The window system bears on and attaches directly to the concrete slab, with connection details provided by the supplier. Metal stud framing is supplied as needed, featuring a gravity connection using screws or welds to the structure. A metal deck is set flush with the steel beam utilizing a continuous 3/8 inch plate and Z-clips for support, accompanied by a 3/16 inch fillet weld.
A A SEE DETAIL FOR CONDITION BTWN BEAMS AND DETAIL FOR INFO NOT NOTED GRID LAP LENGTH 1" CLR FINISHES, SEE ARCH SECTION A-A 3/16 MTL DECK FLUSH W/ BM Z-CLIP TO SUPPORT MTL DECK STL BM 3/8" PL x CONT / (2 S611) / (1 S610) SEE ARCH WINDOW SYSTEM TO BEAR ON AND ATTACH DIRECTLY TO CONC SLAB, CONNECTION OF WINDOW TO CONC SLAB BY SUPPLIER 1 S802 GRAVITY CONNECTION (SCREWS OR WELD) OF STUDS TO STRUCT BY SUPPLIER STUD FRAMING AS NEEDED, BY SUPPLIER S610 12 TYP MTL DECK
