Steel stair stringers sized per plan are joined at angled intersections using complete joint penetration welds. A channel section, also sized per plan, is welded to the stringer assembly with a quarter-inch fillet weld.
CJP CHANNEL SEE PLAN CJP STRINGER SEE PLAN 1/4 STRINGER SEE PLAN CHANNEL SEE PLAN 1/4 A B
