Two diagonal members intersect a horizontal structural chord at a common work point on grid. Internal stiffener plates match the thickness of the brace flanges on each side typical. A grid splice joins the chord segments with a three-eighths inch fillet weld typical on both sides. Complete joint penetration welds connect the diagonal members typical at the work point.
GRID SPLICE STIFFENER PL ES, TYP MATCH BRACE FLG THK ES, TYP 3/8 3/8 CJP TYP WP ℄ CHORD ℄ DIAG ℄ DIAG SEE ELEVATION
