A pipe penetration through a concrete wall footing with specified clearances and sleeve dimensions. A metal sleeve with a diameter equal to the pipe diameter plus two inches is installed through the concrete, featuring a collar around the pipe to prevent dirt intrusion. The design mandates a minimum three and a half inch clearance between adjacent pipe sleeves and limits the maximum penetration depth to three feet. Step footings are applied as required per typical details, with the general contractor coordinating exact depths and locations.
2 1 MAXIMUM EXTENT OF EXCAVATION PROVIDE COLLAR AROUND PIPE TO KEEP DIRT OUT OF SLEEVE WALL FOOTING OPTIONAL CONST JT METAL SLEEVE DIA = PIPE DIA + 2" 3D OR 6" NOTES: 1. STEP FOOTING PER TYPICAL STEPPED FOOTING DETAIL AS REQUIRED TO SATISFY THESE CONDITIONS. 2. GENERAL CONTRACTOR TO COORDINATE EXACT DEPTH AND LOCATION OF PIPE. 3. "D" SHALL NOT EXCEED 8". (WHICHEVER IS GREATER) CLR MIN BETWEEN ADJACENT PIPE SLEEVES 3 1/2" MIN MIN 1'-0" PASS THRU FTG NO PIPES SHALL 3'-0" MAX ELEVATION SECTION MIN 9" MIN 6" D MIN 4"
