Structural · S-43FWR

Elevator Rail Support and Beam Connection Detail

Materials

Timber / Wood

Elements

Beams Floors / Slabs

Connections

Bolted Connection

About this detail

A structural steel beam per plan bears on an elevator rail support per sheet S-528, featuring an eight-inch LSL vertical post with a three-eighths-inch cap plate. The cap plate is secured with three-eighths-inch by seven-inch by zero-foot-eight-inch plates containing two standard bolts, tightened finger only, with a four-inch gauge. A continuous three-eighths-inch plate is welded with three-sixteenths-inch fillet welds spaced at three inches on twelve inches typical. Full depth shear connection plates per sheet S-505 connect the beam web using standard holes and bolts. A concrete slab on metal deck per plan bears on the top flange of the beam, maintaining a five-and-one-half-inch total depth relative to the top of steel elevation.
