Steel beam connections frame into a column with continuity plates and a cap plate at the top of the column. Complete joint penetration welds are specified at the top and bottom flanges with demand critical requirements per AWS D1.8. Three three-quarter-inch diameter erection bolts secure the shear tab connection with typical one-and-a-half-inch and two-inch spacings. Weld access holes are detailed with a one-half-inch minimum radius in the plate.
CONTINUITY PLATE PER PL AND 3/4" DIA ERECTION BOLTS, SEE NOTE 5 WELD ACESS HOLE PER AWS D1.8 CJP TOP AND BOT FLANGE (DEMAND CRITICAL) (DEMAND CRITICAL) TYP 1 1/2" 1" 2" (DEMAND CRITICAL) CONTINUITY PLATE PER AT TOP OF COL PROVIDE CAP PL W/ SIM SHPAE WELDED PER STRONG AXIS CONDITION (DEMAND CRITICAL) 1/2" MIN RADIUS IN PL CAP PL AT TOP OF COLUMN CJP TOP AND BOT FLANGE (DEMAND CRITICAL) 2" 1" (DEMAND CRITICAL) 1 1/2" 3/4" = 1'-0" 08 CONTINUITY PLATES
