Steel tube stair stringers frame into a steel tube beam at a floor landing consisting of concrete over steel deck. A one-quarter-inch thick steel closure plate caps the end of the stringer, welded with typical complete joint penetration welds. An infill steel tube beam spans between the stringers. An L3x3x1/4 angle of required length provides additional connection support at the underside of the landing slab.
CONC OVER STEEL DECK STEEL TUBE STAIR STRINGER BEYOND STEEL TUBE BEAM STEEL TUBE STAIR STRINGER 1/4" THICK STEEL CLOSURE PLATE AT END OF STRINGER TYP CJP TYP 1/4 1/4 TYP INFILL STEEL TUBE BEAM BTWN STRINGERS D4 SF532 L3x3x1/4 x LENGTH REQ'D
