A concrete masonry unit wall connects to a concrete slab on grade, with elevated slab installations following similar detailing. Two continuous number five reinforcing bars run horizontally through the slab, while vertical continuous dowels match the wall reinforcing and feature alternate hooks embedded in the thickened slab section. A forty-eight bar diameter lap splice connects the vertical dowels to the wall reinforcement. Slab reinforcement is sized per the structural plans.
SEE PLAN FOR TYP SLAB REINF NOTE: SLAB ON GRADE SHOWN, ELEVATED SLAB SIMILAR 2#5(B) CONT DOWELS TO MATCH VERTICAL REINFORCING ALTERNATE HOOK CMU WALL - SEE SCHEDULE FOR REINFORCING 1'-6" PLAN SEE GRADE 10" AT DIA LAP 48 BAR
