A flat core plate is installed centrally within the void and surrounded by grout fill. A proprietary interface material is positioned at the perimeter of the embedded plate. The detail indicates symmetrical conditions about the centerline.
SYM ABT 2A S-630 tc FLAT CORE PLATE DET. (CTR'D) GROUT FILL PROPRIETARY INTERFACE MATERIAL (PIM)
