A structural steel drag strut connection framing wide-flange beams into a steel column with a fifty KSI steel cap plate sized to match the beam flange width and thickness. The cap plate is welded to the column web with a five-sixteenths inch fillet weld. A three-quarter-inch by six and one-eighth-inch girder bearing plate is attached below. Wide-flange beams connect via shear tabs welded with seven-sixteenths inch fillet welds on three sides, designated as slab longitudinal collector drag struts on plan. A metal roof deck spans above the framing members.
STL COL 50 KSI STL CAP PL TO MATCH BM FLANGE WIDTH AND THICKNESS GIRDER BRG PL 3/4"x6 1/8" MTL ROOF DECK 3 SIDES 5/16 3 SIDES TYP AT BMS DESIGNATED AS (SLRSC) ON PLAN 7/16 BF BM WF BM CJP DCW (3) SIDES 7/16 5/16 CAP PL TO COL WEB 14 S702 TYP AT SIM
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
